Denture mechanic average bite calibrator

Product Description

Denture mechanic average bite calibrator

The jaw frame calibration column is mainly used for the calibration of the mean jaw rack and the semi-adjustable jaw rack.

First, use method
1. Prepare the jaw rack and adjust the scale of each part, open the maxillary body of the jaw frame, and place it horizontally
2. Remove the base of the mandibular body, find a small piece of paper to block the central hole of the mandibular body, prevent the glue from flowing out of the hole in the later bonding process, affect the distance between the jaws after solidification, and can not successfully remove the magnet .
3. Mix A and B glues in a ratio of 1:1. Mix evenly.

Bonding:
1 Place the adjusted AB glue in the recess on the back of the base of the mandibular body.
2 The gums are also glued on the ball tips on both sides of the mandibular body.
3 The prepared calibration column is attached to the mandibular black trapeze plate
4 Put the whole body on the jaw rack again, check the tightness of the calibration column and the black trapezoidal disk, and reconfirm the scale of each part of the jaw frame.
5 Unscrew the screw shaft, put the jaw frame upside down, and press with a heavy object to prevent the glue from swelling
6When the glue is completely solidified, the calibration column can be removed

Second, common problems and handling
1. Problem: When bonding, no heavy objects are pressed, glue swells, jaw spacing is changed, and interchange is not achieved.
2. Treatment: Apply heavy weights during bonding
3. Problem: Foreign matter cannot appear on the calibration column and the black trapezoidal disc to prevent the distance between the jaws from changing
4. Treatment: Before calibration, check that the calibration column is clean.
5. When determining the intermaxillary distance, remember to adjust the scale of each part of the jaw rack.
6. Be careful to check the calibration column for defects at all times; the calibration column base is clean;
7. The scale of each part of the jaw frame: lateral guide 15 degrees, cutting 0 degrees.
Third, maintenance and cleaning
1. Regularly check the cleaning of the calibration column
2. Periodically check the alignment bar between the jaw frames
3. It is forbidden to clean the calibration column with a sharp instrument, so as not to damage the paint layer on the calibration column surface, resulting in inaccurate calibration of the jaw rack.
4. Use a soft cloth to pick up the cleaning solution and wipe it to remove dirt.
5. Do not use hot water or steam gun for cleaning.
